Tyre Pyrolysis Plant

  • Print
Using the most cost effective recycling technology, Tyre Recycling Plant has become a complete choice among many customers. The outcome is almost 100% and the process does not leave any waste behind. Moreover, the system is eco friendly as it does not generate pollution and produce valuable products, having good market demand. Our offered range is integrated with unrivaled characteristics, including rugged design, optimum performance, high durability and abrasion resistance body. Thus, known to produce an alternate source of energy, this minimizes the usage of petroleum products and natural gases.

RC-10

Equipment type FI – RF-10
Raw material Nylon / Radial Tyre
Structural form Horizontal rotation
24-hour Capacity 8.5 ton
Oil yield [40 to 45% oil] 3.8 ton
Steel Scrap [15 to 20%] 1.7 ton
Carbon [30 to 35 %] 2.5 ton
Operating pressure Normal ( 0.1 To 0.3 Kg)
Material of Reactor SS PLATE
Thickness of Reactor 14 mm
Rotate speed of Reactor 0.3turn/minute
Total power 25KW
Mode of Water cooling Circular cooling
Cooling area of condenser 51 Sq.Meter
Kind of transmission Dual Motor Arrangement
Noise dB(A) ≤85
Size of Reactor(D×L) 2.6×6.6 Mt.
Working form Intermittent operation
Lend Requirement 10,800 Sq Feet.
Delivery time 10 Days
Installation Time 15 To 20 Day
Training Time 5 Days

RC-12

tem Model
Equipment type FI – RF-12
Raw material Nylon / Radial Tyre
Structural form Horizontal rotation
24-hour Capacity 10.5 ton
Oil yield [40 to 45% oil] 4.4 ton
Steel Scrap [15 to 20%] 1.6 ton
Carbon [30 to 35 %] 3.6 ton
Operating pressure Normal ( 0.1 To 0.3 Kg)
Material of Reactor SS PLATE
Thickness of Reactor 16 mm
Rotate speed of Reactor 0.3turn/minute
Total power 33KW
Mode of Water cooling Circular cooling
Cooling area of condenser 77 Sq.Meter
Kind of transmission Dual Motor Arrangement
Noise dB(A) ≤85
Size of Reactor(D×L) 2.8×6.6 Mt.
Working form Intermittent operation
Lend Requirement 10,800 Sq Feet.
Delivery time 10 Days
Installation Time 15 To 20 Day
Training Time 5 Days

RF-5

RF-5 is specially designed to converts the waste materials and tyres into pyrolysis oils, fuel and energy.

tem Model
Equipment type FI – RF-5
Structural form Horizontal rotation
Oil yield [40 to 45% oil] 1.72 ton
Carbon [30 to 35 %] 1.29 ton
Material of Reactor SS PLATE
Rotate speed of Reactor 0.3turn/minute
Mode of Water cooling Circular cooling
Kind of transmission Dual Motor Arrangement
MSize of Reactor(D×L) 2.2×6.0 Mt.
Lend Requirement 10,800 Sq Feet.
Installation Time 15 To 20 Day
Raw material Nylon / Radial Tyre
24-hour Capacity 4.3 ton
Steel Scrap [15 to 20%] 0.86 ton
Operating pressure Normal ( 0.1 To 0.3 Kg)
Thickness of Reactor 12 mm
Total power 20KW
Cooling area of condenser 20 Sq.Meter
Noise dB(A) ≤85
Working form Intermittent operation
Delivery time 10 Days
Training Time 5 Days
